TPF-4
TPF-4 TPF-4

TPF-4

8 10 15 20 30 40 Kg
REQUEST A QUOTE

Product information

Applications

Bench platforms up to 400x400mm

Features

Single point load cell
Bending beam load cell
Fully stainless steel contruction
3000 divisions OIML R60 Class C
Direct platform mounting
High accuracy with off-center loads
Low profile
Protection against humidity IP66(EN60529)

Technical specifications

Nominal capacitites (LN) (C3)      8-10-15-20-30-40 kg
Accuracy class      3000 n. OIML
Minimum dead load      0 %LN
Carga Service load      150 %LN
Safe load limit      200 %LN
Maximum combined error      0,017 %Sn
Repeatability error      0,015 %Sn
Temperature effect      0,01 %Sn/5ºC
On cero on sensitivity      0,006 %Sn/5ºC
Creep error      0,016 %Sn
Temperature compensation      -10..40ºC
Temperature limits      -20..50ºC
Nominal sensitivity      2±0.1% mV/V
Nominal input voltage      10V
Maximum input voltage      15V
Input resistance      386±2%
Output resistance      350±3
No load output (SN)      2 %Sn
Insulation resistance      >5000 MOhms
Cable length      5m

Documentation

TPF-4 technical data Download
OIML R60 certifiacate Download
