CP-2
CP-2
Compression
Voir d'autres produits Compression
500
750
1000
2000
5000
7500
10000
12000
20000
25000
30000
Kg
DEMANDER UN DEVIS
Informations sur le produit
Applications
Test benchesVerification presses
Low profile
Caractéristiques
Compression load cellFully stainless steel contruction
Hermetically sealed
Protection against humidity IP68(EN60529)
Spécifications techniques
| Nominal capacity (LN) | 500-1000-2500-5000-7500-100000-12000-15000-20000-30000 kg |
| Accuracy class | 1000 n. OIML |
| Minimum dead load | 0 %LN |
| Service load | 150 %LN |
| Safe load limit | 200 %LN |
| Maximum combined error | 0,017 %Sn |
| Repeatability error | 0,015 %Sn |
| Temperature effect | 0,01 %Sn/5ºC |
| On cero on sensitivity | 0,006 %Sn/5ºC |
| Creep error | 0,016 %Sn |
| Temperature compensation | -10..40ºC |
| Temperature limits | -20..50ºC |
| Nominal sensitivity | 2±0.1% mV/V |
| Nominal input voltage | 10V |
| Maximum input voltage | 15V |
| Input resistance | 766±2% |
| Output resistance | 700±3 |
| No load output (SN) | 2 %Sn |
| Insultaion resistance | >5000 MOhms |
| Cable length | 5m |
