GS-1A

Applications

Hybrid scales
Fully electronic scales
Silos, Hopper wighing and tanks
Platforms 4 load cells
Industrial environments

Caractéristiques

Bending/Shear beam load cell
Stainless steel construction
4000 divisions OIML R60 class C
Hermetically sealed by laser welding
Protection against humidity IP68 (EN60529)

Spécifications techniques

Nominal Capacities (LN)	15*-30*-50-75-100-150-200-300-500*-750*-1000*-1500* kg
Accuracy class	4000 n. OIML
Minimum dead load	0 %LN
Service load	150 %LN
Safe load limit	200 %LN
Maximum combined error	0,017 %Sn
Repeatability error	0,015 %Sn
Temperature effect	0,01 %Sn/5ºC
On zero on sensitivity	0,006 %Sn/5ºC
Creep error	0,016 %Sn
Temperature compensation	-10..40ºC
Temperature limits	-20..50ºC
Nominal sensitivity	2±0.1% mV/V
Nominal input voltage	10V
Maximum input voltage	15V
Input resistance	386±2%
Output resistance	350±3
No load output(SN)	2 %Sn
Insultaion resistance	>5000 MOhms
Cable length	5m
