TPP-1

Applications

Bench platform up to 600x600mm
Hopper weighing

Caractéristiques

Single point load cell
Bending beam load cell
Fully stainless steel contruction
3000 divisions OIML R60 Class C
Direct platform mounting
High accuracy with off-center loads
Low profile
Protection against humidity IP67(EN60529)

Spécifications techniques

Nominal capacity (LN)	50kg
Accuracy class	3000 n. OIML
Minimum dead load	0 %LN
Service load	150 %LN
Safe load limit	200 %LN
Maximum combined error	0,017 %Sn
Repeatability error	0,015 %Sn
Temperature effect	0,01 %Sn/5ºC
On cero on sensitivity	0,006 %Sn/5ºC
Creep error	0,016 %Sn
Temperature compensation	-10..40ºC
Temperature limits	-20..50ºC
Nominal sensitivity	2±0.1% mV/V
Nominal input voltage	10V
Maximum input voltage	15V
Input resistance	386±2%
Output resistance	350±3
No load output (SN)	2 %Sn
Insultaion resistance	>5000 MOhms
Maximum deflection	0,2-0,6
Cable length	5m
